The Nushell Plugin

Nushell treats every pipeline as a table (list<record>), which makes it a natural front-end for a grammar-of-graphics library: instead of serializing data to CSV and re-loading it into a plotting tool, you can pipe a table straight into a chart. nu_plugin_charton is the bridge that turns Charton into a first-class citizen of the shell.

open sales.csv | charton bar -x region -y revenue

That single line reads a file, infers column types, builds a Charton Dataset, renders a bar chart, and draws it inline in the terminal.

charton drawing a bubble chart inline in the terminal

This chapter is the conceptual overview. The complete flag/config reference lives in the plugin's own README. The non-obvious engineering — process model, inline protocols, resolution fitting, protocol versioning — is covered in Nushell Plugin Internals.

Why a plugin, not a binary

A Nushell plugin is a long-lived child process that speaks Nushell's plugin protocol (MessagePack over stdio or a local socket). Packaging Charton as a plugin rather than a standalone CLI buys three things:

No serialization round-trip. Data arrives as Nushell Values and is converted directly into a Charton Dataset. There is no CSV/JSON detour and no second parse.
Composability. The command can hand values back to the pipeline (--raw), so a chart is just another stage: ... | charton point -x a -y b --raw | save chart.svg.
Terminal-native output. The plugin inherits the shell's stdout, so it can draw the chart inline in the terminal — the shell equivalent of plt.show().

The data path

Nushell Value (list<record>)
        │  converter.rs  (per-column type inference over all rows)
        ▼
      Table
        │  command.rs    (mark subcommand → mark, --transform, --layer, facets)
        ▼
   Charton Dataset / LayeredChart
        │  render.rs
        ├─► SVG string      (vector — export / pipe)
        └─► PNG bytes       (raster — inline / export)
                │  render.rs
                ▼
     Terminal escape sequence (Kitty / iTerm2 / Sixel / half-block)

Type inference is done over all rows, not just the first: a column that starts with integers but contains a decimal later is promoted to float, and a column containing nulls/NaNs stays null-aware. This mirrors the integrity rules described in The Dataset Struct.

Quick start

Install

cargo install --path nu_plugin_charton --locked

Add the plugin to Nushell's registry:

plugin add '~/.cargo/bin/nu_plugin_charton.exe'   # Windows: full path is most reliable

Then load its commands in the current session:

plugin use charton

plugin use is a parser keyword, so the two lines must be separate inputs, not one script.

The full, platform-specific walk-through (including uninstall) is in the plugin README.

First chart looks blurry? Nothing is wrong. With no inline_style configured the plugin uses the universal halfblock renderer, which works on every terminal but is soft. Set the protocol once in $env.config.plugins.charton (iterm2, kitty, or sixel) for sharp bitmap output.

Everyday use

# inline
ls | charton bar -x name -y size

# export by extension: SVG is a vector, PNG is a raster
open data.csv | charton line -x date -y value -o chart.svg
open data.csv | charton point -x group -y score --layout beeswarm -o chart.png

# violin: the density outline (`examples/violin.rs`); -c dodges one per group
open data.csv | charton violin -x category -y score -c group -o violin.svg

# contour: iso-lines of a regular x/y/z grid; --z is the value column
open grid.csv | charton contour -x x -y y --z z -o contour.svg

# group by a column with a color channel, then overlay a second mark
open data.csv | charton line -x t -y v -c series --layer point

# recipes are compositions, not marks: --transform runs Charton's public
# transforms in order and the mark draws the columns they emit
# ridgeline = density + one-sided band + polygon
let ridge = [
    {op: density, field: score, as: [value, density], group-by: [category]}
    {op: band, value: value, width: density, center: category, side: right,
     scale: per-group, overlap: 2.5, band-width: 1.0, as: [x, y, pg]}
]
open assets/data.csv
| charton polygon -x x -y y --path-group pg -c category --flip \
    --opacity 0.85 --stroke '#2c3e50' --stroke-width 1.0 --transform $ridge -o ridge.svg
# ECDF = the CumeDist window transform + a step line
let ecdf = {op: window, field: score, kind: cume-dist, as: ecdf, group-by: [group]}
open assets/data.csv
| charton line -x score -y ecdf -c group --interpolation step --transform $ecdf -o ecdf.svg
# candlestick = a low--high rule + a floating bar
let body = {geom: bar, y: open, y2: close}
open assets/ohlc.csv
| charton rule -x date -y low --y2 high -c direction --layer $body --x-angle -45 -o candles.svg
# dumbbell = a rule with a dot at each end
let ends = [{geom: point, y: y2011}, {geom: point, y: y2021}]
open assets/dumbbell.csv
| charton rule -x country -y y2011 --y2 y2021 --flip --layer $ends -o dumbbell.svg
# range = a single rule; slope = a line with its points
open assets/range.csv | charton rule -x month -y low --y2 high --flip -o range.svg
open assets/slope.csv | charton line -x period -y rate -c country --layer point -o slope.svg

# geographic choropleth from GeoJSON
charton geo --geojson world.geojson -c POP_EST -o world.png

The plugin is built around four levels, from "just draw my rows" to writing a full recipe: marks (geometry primitives and statistical atoms), composition (--layer), transforms (--transform), and both together. The README's four-level guide walks through them.

The mark subcommands cover every Charton mark (charton point, charton line, charton path, charton polygon, charton area, charton bar, charton boxplot, charton violin, charton errorbar, charton rule, charton tick, charton text, charton rect, charton hist, charton density, charton density-2d, charton contour, charton geo). Chart types that Charton builds from primitives — ridgeline, ECDF, candlestick, dumbbell, range, slope, bump, waterfall, raincloud, violin-with-box — are not commands: you write them with --transform and --layer, exactly as the cookbook shows. The --transform vocabulary is closed: density, density-2d, contour, band, quantile-box, window, calculate. A transform record says what to run (op), which columns to read (field, x, y, ...), and what to call the new columns (as). Writing Transforms explains every key, lists the options, and builds the recipes step by step.

Configuration

Defaults live in $env.config.plugins.charton. Command-line flags win over config, and config wins over built-in defaults:

$env.config.plugins.charton = {
    width: 1000
    height: 700
    scale: 1.0                     # output pixels = width × scale
    cell_width: 9                  # terminal cell size in device px
    cell_height: 20                # (tune if inline charts look soft)
    inline_style: kitty            # halfblock (default) | iterm2 | kitty | sixel
    grid: true
    palette: tab10
    legend: bottom
    x_angle: -45
    background: "#ffffff"
}

inline_style tells the plugin which image protocol your terminal supports; set it once per terminal. The default halfblock works everywhere. cell_width/cell_height are the other non-obvious knob; both are explained in Nushell Plugin Internals.
